Scissor Car Lift

        Discover the Perfect Cargo Lift for Your Needs

All You Need To Know About Scissor Car Lift

Table of Contents

The Basic of Scissor Car Lift

XYZLIFT is a renowned industry leader in the manufacturing of scissor car lifts, offering a comprehensive range of high-quality products. With their expertise, XYZLIFT provides customized solutions tailored to the specific car size and requirements of customers. These scissor car lift platforms are the ideal choice for home car parking in garages and underground spaces.

One of the key advantages of XYZLIFT’s scissor car lift platforms is their versatility. They can be designed to rotate, making them suitable for car parking spaces with limited dimensions. This innovative feature allows for efficient utilization of available space, maximizing the number of vehicles that can be accommodated.

Moreover, XYZLIFT’s scissor car lifts are not limited to residential use alone. They also serve as excellent solutions for car shows, providing a secure and elevated platform to showcase vehicles in a professional and visually appealing manner.

XYZLIFT takes pride in the robust structure and supporting frames incorporated into their scissor car lift designs. This ensures that the lifts can be easily installed in any type of environment or installation site. Whether it is a small home garage or a large commercial space, XYZLIFT’s professional team is equipped to handle diverse requirements.

Our Ranges of Scissor Car Lift

Find the Perfect Scissor Car Lift for Your Business Needs

Standard Scissor Car Lift

Loading capacity 5t,lifting height within 3.5m

Heavy Duty Scissor Car Lift

Load capacity more than 8t,lifting height more than 4.5m

Special Scissor Lift on Sale

 5 Customized Goods Lift with Special Surface Treatment or Functions

Galavnized Scissor Car Lift
Scissor Car Lift With Turnable

Not found what you are looking for?

We could still help! Contact our team to find out more.

Scissor Car Lift Model List

Model Load capacity Lift height Platform size
XYZSL-2.8 3000kg 2800mm 2500*5800mm
XYZSL-3 3000kg 3000mm 2500*6000mm
XYZSL-3.5 5000kg 3500mm 3000*6000mm
XYZSL-4 5000kg 4000mm 3000*6000mm

Major Components for Scissor Lift

This is what we do when it comes to making wholesale coconut bowls:



1 of 6


2 of 6

Base frame

3 of 6

Hydraulic Pump

4 of 6

Hydraulic Cylinder

5 of 6

Control Box

6 of 6


Scissor car lift platform surface features an anti-slip patterned board, measuring 8mm in thickness, to prevent car tire sliding and ensure secure traction. The base structure of the platform is engineered to load capacities and lift heights, providing stability during lifting operations. To enhance safety, an electric toe guard is positioned under platform, automatically stopping the descent if it comes into contact with barriers.



The scissor structure of our car lift is constructed using standardized rectangular steel tubes, carefully selected to meet the load capacity and platform size requirements. We prioritize the use of SF-1 wear-resistant and galvanized bearings for the scissor car lift, ensuring durability and smooth operation even after extended periods of use. In cases where a lower closed height is needed, our design incorporates steel plates, precisely determined in thickness to accommodate the load capacity and platform size of the scissor car lift.


Base frame

The base of our scissor car lift is constructed using strong channel steel, reinforced with rectangular steel tubes to enhance the overall structure's strength and stability. With four posts incorporated into the base, adjusting the scissor car lift platform's closed height to fit the designated pit is a seamless process. To provide added convenience, we have welded a crane hole onto the scissor car lift base, enabling easy movement and transportation of the lift.


Hydraulic Pump

Our scissor car lift's pump station is installed inside the lift and securely fixed to the bottom base. A maintenance hole on the platform provides convenient access. The power station's location can be customized as per customer requirements. We prioritize quality and reliability, using Siemens brand pumps. Our pump stations also feature an emergency decline function for safe and controlled lowering during emergencies.


Hydraulic Cylinder

Our scissor car lift is equipped with two strong cylinders, ensuring efficient lifting performance. These cylinders are connected using a T connection hydraulic pipe, ensuring that hydraulic oil fills both cylinders simultaneously. The size of the cylinders is determined based on the lift height and load capacity requirements. To prioritize safety, the cylinders are equipped with anti-explosion features. In the event of damage to the oil pipe, the platform will not suddenly descend, further enhancing safety during operation.


Control Box

Our scissor car lift control box is designed with voltage protection, automatically cutting power if the voltage exceeds or falls below the set voltage for safe operation. Each floor is equipped with a dedicated control panel featuring an emergency stop button to ensure maximum safety. We prioritize quality and reliability in our electrical components, which is why we select renowned brands like Omron and Schneider.

Scissor Car Lift Standard Safety

We adhere to the EN81-31 and national Chinese elevator industry standards, with quality management in line with ISO9001, to provide users with a safer Scissor Car lift

Hydraulic System

  • Overload Protection: If the load exceeds the predetermined weight limit, the scissor car lift will activate a warning mechanism, alerting the operator to ensure the car being lifted is within the suitable weight range.

  • Emergency Descent Valve: An easily accessible emergency decline valve is located outside the motor, allowing for quick and convenient lowering of the lift during emergency situations. This prioritizes safety and provides a reliable solution for prompt action.

  • Hydraulic Cylinder with Anti-Explosion Proof Valve: The cylinders of our scissor car lift are equipped with anti-explosion proof valves. In case of damage to the hydraulic oil pipe, these valves prevent the oil from flowing back to the tank and effectively block the platform from descending, enhancing safety measures.

  • Pump Station with Protective Case: The pump station of our scissor car lift is securely housed in a protective cabinet, safeguarding it against rain and sand. This protective enclosure ensures the longevity and reliable performance of the pump, even in challenging environmental conditions.

Control System

  • Emergency Stop: Each floor control panel and electric box are fitted with an emergency stop button, allowing for immediate cessation of the scissor car lift’s movement during emergencies.

  • Final Limit Switch: To further enhance safety, we incorporate a final limit switch in addition to the standard top floor level limit switch. In the event of damage to the top floor level limit switch, the final limit switch will engage, stopping the scissor car lift from operating.

  • Electric Parts: We utilize high-quality electric parts from trusted brands such as Omron and Schneider. Additionally, our system includes voltage protection, automatically shutting off the electric box if the voltage falls below or exceeds the preset range.

  • Key Switch: A key switch is provided to cut off the power supply to the scissor car lift. This feature allows authorized personnel to control access to the equipment and secure its operation.


  1. Maintenance Support Bar: Two maintenance support bars are positioned at the end of the scissor structure. These bars prevent the scissor structure from lowering when someone is underneath the platform, providing additional safety.

  2. Electric Toe Guard: The platform is surrounded by safety bars on all four sides. In the event of the lift descending and making contact with a barrier, the lift will immediately stop its downward movement, ensuring the safety of individuals and preventing accidents.

  3. Anti-Slip Platform Surface: The platform surface is constructed with an anti-skid steel plate, designed to prevent car tires from sliding during the lifting process. This feature enhances traction and ensures a secure grip for vehicles.

  4. Platform Rails: To safeguard vehicles during travel between floors, we have added 1.1m height rails to the platform. These rails provide additional protection and prevent cars from accidentally rolling off the lift.

How to Install

Free Assebmled of Scissor Car Lift

XYZLift takes great pride in the meticulous assembly of our scissor car lifts, which includes the precise connection of the electric control system. We understand the importance of a hassle-free experience for our customers, starting from the installation process.

Installing our scissor car lifts is a breeze. With our user-friendly design, all you need to do is securely fix the lift in the designated pit using the provided bolts. Rest assured, XYZLift supplies all the necessary bolts for installation, eliminating the need for additional purchases or sourcing.

We are comm

Scissor Car Lift Video Show

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.

Operation & Maintenance

If you encounter any problems while using our scisor car lift, our experienced after-sales team will assist you in resolving them quickly.

Safety first concept.
Safety Instruction

Safety instructions posted next to scissor car lift control buttons for secure machine operation.

Operation Guideline

before operate scissor car lift, ready operation giuideline to operate scissor lift on right way

Maintenance Engineer
Maintenance Guideline

We provide a detailed daily maintenance checklist to ensure proper upkeep of the scissor car lift.

Most Frequently Questions.

What we are thinking is all about your safty!

The delivery time for our scissor car lifts is 3–5 weeks from the order deposit.

To accurately specify a scissor car lift, we require the following information:Load capacity: Weight and type of car to be lifted
Platform size: Size is bigger than your car or shaft size we design the car size accordingly.
Travel height: Distance between floors
Special functions or requests: lower closed height,galvanized scissor car lift etc.

Our car lift can travel up to 11m, covering 4 floors.

Our heavy-duty scissor car lift can lift items weighing up to 50 tons, for lifting one truck.

Please provide the interested RAL color number, and we will produce the scissor car lift accordingly.

The Cost of Scisso car Lift

Scissor car lift price according to load capaicty, lift height and platform size. The price is subject to fluctuations in the cost of raw materials, changes in exchange rates, and variations in the brand of accessories and add-on equipment.

One Scissor Car Lift Cost Include

Factors Influence Scissor Car Lift Price

  1. Fluctuations in raw material prices
  2. Complexity of features
  3. Requirements for electrical components and motor brands
  4. Fluctuations in freight charges
  5. Exchange rate fluctuations

Custom Scissor Car Lifts That Suits Your Need

You will get accurate lift solution in 24 hours.Please supply main information as follows

Send a Message

Ask For A Quick Quote

We will contact you within 1 working day, please pay attention to the email

Or contact us by whatsapp +86-18366130656

Safety Instructions for Scissor Car Lift

  1. Only trained and authorized personnel should operate the equipment.
  2. The scissor car lift should not be used to lift people.
  3. Do not exceed the Safe Working Load (SWL) of the lift platform.
  4. Ensure that loads are centered on the lift platform.
  5. If the load is mobile, secure it in a fixed position before operating the lift.
  6. Keep the entire load within the perimeter of the platform during lift operation.
  7. Maintain clear areas beneath the platform and around the lift’s perimeter while it is in motion.
  8. Never work under the lift without the maintenance device(s) in place.

Operation Guideline for Scissor Car Lift

  1. Turn the power switch to “ON” after inserting the key.
  2. Release the Emergency Stop Button on the power station and control boxes.
  3. Ensure all doors are closed before operating the Lift Platform.
  4. Press the UP Button to raise the Lift Platform until it reaches the designated upper height.
  5. Press the DOWN Button to lower the Lift Platform until it reaches the designated lower height.
  6. Press the Emergency Stop Button in case of an emergency to halt the movement.
  7. In the event of control or power failure, open the Emergency Down Valve to lower the Lift Platform to the parking position.
  8. Turn off the Lift Platform by lowering it to the parking position and switching the power key to the “OFF” position.

Maintenance Guideline for Scissor Car Lift

  1. Daily inspection

Daily inspection is effective to find the malfunction or fault on the scissor car lift. Before operation, check the lift according to the following points.

CAUTION!   Do not use the scissor car lift if any malfunction or fault is found.

  • Check scratches, bending or crack on the lift.
  • Check smooth movement of the platform.
  • Check control panel ensure well working.
  • Check if there is any hydraulic oil leakage.
  • Check the vertical creep of the platform.
  1. Maintenance instructions
Inspection Contents Standard
Every 1 month
Lubricate all the joints and pivot points Keep lubricated
Limit switch for all floors Running normally
Guard-lock switch for landing door Running normally
Guard-lock switch for platform door Running normally
Motor pump station Running normally
Warning light Running normally
Control cabinet terminals No looseness, no damage
Chains No looseness, no damage
Wire ropes No looseness, no damage
Guide rails No deformation
Guard net No damage
All electric wires No damage
Accompanying cable No damage
Every 6 months
Check oil level of oil tank Keep clean and no oil leakage
Check the cleanliness of oil filter Keep clean
Fasten all the connecting parts again Fastened tightly
Check wear and tear of pressure oil pipes Replace new one if badly worn
Check hydraulic cylinder Keep no oil leakage
Fix main parts tighten again Fastened tightly
Check the function of micro-switches Running normally
Check whole working state of the lift Running normally
Every 1 year
Check wear and tear of all axial bushes No damage
Replace hydraulic oil Accumulated working 1000 hours
Check oil leaking No oil leakage
