Our Material Lift
AML
Heavy Duty Material Lift
SML
Light Duty Material Lift
Material Model List
| Parameter | AML3 | AML4.5 | AML6 | AML7.5 | SML3.3 | SML4.4 | SML5.5 |
|---|---|---|---|---|---|---|---|
| Working Height (Fork up) | 3.49m | 4.98m | 6.46m | 7.94m | 3.8m | 4.9m | 6m |
| Working Height (Fork down) | 2.97m | 4.46m | 5.94m | 7.42m | 3.3m | 4.4m | 5.5m |
| Stowed width | 0.8m | 0.8m | 0.8m | 0.8m | 0.8m | 0.8m | 0.8m |
| Stabiliser width | 1.85m | 1.85m | 1.85m | 1.85m | 1.63m | 1.63m | 1.63m |
| Stowed length | 0.74m | 0.74m | 0.74m | 0.74m | 0.74m | 0.74m | 0.74m |
| Operating length | 1.51m | 1.88m | 2.08m | 2.08m | 1.72m | 1.85m | 2.1m |
| Stowed height | 1.99m | 1.99m | 1.99m | 1.99m | 1.6m | 1.6m | 1.6m |
| Fork length | 0.75m | 0.75m | 0.75m | 0.75m | 0.75m | 0.75m | 0.75m |
| Max. load capacity (Top row)* | 454kg | 363kg | 363kg | 295kg | 318kg | 295kg | 272kg |
| Max. load capacity (Middle row)** | 454kg | 363kg | 295kg | 204kg | 200kg | 195kg | 181kg |
| Max. load capacity (Bottom row)*** | 181kg | 227kg | 159kg | 113kg | 84kg | 80kg | 80kg |
| Overall Weight | 148kg | 176kg | 205kg | 231kg | 125kg | 138kg | 156kg |
Major Components for Material Lift
1
2
3
4
5
6
7
8
9
10
11
12
1
Lifting pipe
7
Rope wheel
2
First section of the rope pulley system
8
Mast maintenance hole
3
winch
9
Mast lower limit switch
4
Bearing clamp
10
Mounting plate and upper limit plate
5
Stabilizer rotating joint
11
Insert and remove the pins for income and expenditure.
6
Sequential lifting device
11
Outrigger support wheels
Custom Material Lift That Suits Your Need
You will get accurate lift solution in 24 hours.Please supply main information as follows
