Industrial Rail Transfer Carts | 2T-500T Custom Track Solutions
XYZLift designs heavy-duty rail transfer carts for demanding industrial transport. Our track-based solutions deliver:
✓ Unmatched Capacity Range
Custom-engineered transfer carts with track from 2T to 500T loads – proven in steel mills, ports, and automotive plants.
✓ Multi-Power Flexibility
Choose optimal drive systems:
Conductor Rail Carts: Kilometre-range power | 500T capacity
Battery Transfer Carts: Track-switch friendly | 8h LiFePO4 runtime
Cable Drum Systems: Cost-effective ≤50m runs
Low-Voltage Carts: 36V operation for hazardous areas
✓ Precision Customization
Deck sizes/load capacity: According to customer requirements
Surface options: Anti-slip/SUS304/heat-resistant
Rail compatibility: P18-P50 standard or custom gauge
Rail Transfer Cart Models: 2T-500T Track-Based Industrial Transporters
Compare 20+ Engineered Series: Conductor Rail, Battery & Custom Deck Solutions | Instant Spec Sheets
| MODEL | XYZCPL-5 | XYZCPL-10 | XYZCPL-20 | XYZCPL-50 | XYZCPL-100 |
|---|---|---|---|---|---|
|
Load Capacity |
5000kg |
10000kg |
20000kg |
50000kg |
100000kg |
|
Platform Length |
2200mm |
2300mm |
2400mm |
2600mm |
3000mm |
|
Platform Width |
2000mm |
2000mm |
2200mm |
2600mm |
3000mm |
|
Platform Height |
500mm |
550mm |
600mm |
800mm |
1200mm |
|
Wheel Base |
1650mm |
1650mm |
1650mm |
2000mm |
2000mm |
|
Axle Base |
1680mm |
1700mm |
1850mm |
2850mm |
4000mm |
|
Wheel Quantity/Diameters |
4/300mm |
4/350mm |
4/400mm |
4/600mm |
8/600mm |
|
Clearance |
50mm |
50mm |
50mm |
50mm |
75mm |
|
Move Speed |
0-25 m/min |
0-25 m/min |
0-25 m/min |
0-25 m/min |
0-25 m/min |
|
Motor Power |
2*1.5kw |
2*2.2kw |
2*4.5kw |
2*7.5kw |
40kw |
|
Battery |
180AH/48V |
250AH/48V |
400AH/48V |
500AH/78V |
1000AH/72V |
|
Running Time With Full Load |
3H |
3H |
2.5H |
2.5H |
2H |
Customize Your Transfer Cart: Size,Optional Battery, Steering & Control Systems
Load capacity 2T-500T
Platform size According to customer
Platform height According to customer
Navigation Magnetic Stripe System（Optional)
Battery Free-Maint.
Explosion-Proof
1200°C Resistant
Steering 4-Wheel Crab Mode
Point Turn
Synchronized Multi-Cart
